Technical Data
Additional data
-
Tripod thread: 1/4"
-
Measurement time, typical: 0.5 s
-
Laser diode: 635 nm, < 1 mW
-
Measuring range: 0.05 – 50.00 m
-
Laser class: 2
-
Measurement accuracy, typical: ± 1.5 mm
-
Measuring range for inclination measurement: 0 – 360° (4 x 90°)
-
Measurement accuracy (typical): ± 0.2°
-
Maximum measurement time: 4 s
-
Power supply: 2 × 1.5 V LR03 (AAA)
-
Automatic switch-off device: 5 min
-
Approx. weight: 0.1 kg
-
Units of measurement: m/cm, ft/inch
-
Memory capacity (values): 20
-
Battery life, individual measurements, approx.: 10,000 measurements
-
Battery life, operating time, approx.: 2.5 h
-
Dust and splash protection: IP54
-
Laser color: Red
-
Measuring range, up to: 50 m
